Tour AD IZ Wood Shafts



Brand new for the 2018 season, Graphite Design introduces the latest in the Tour AD premium line
of golf shafts, the Graphite Design Tour AD IZ – “ Into the Zone” . Designed and manufactured at the
Graphite Design Japan factory headquarters, the new Tour AD IZ wood shaft has a very stealthy
look to it in black with white/orange accents and a sleek new matte finish. The Tour AD IZ shafts
are available in 40g R2, R1 and S flex, 50g R2, R1 and S flex, 60g SR, S and X flex, 70g S and X flex and
80g S and X flex. Additionally, Graphite Design will offer a 50 gram X Flex within the IZ model line-
up for the first time.

The Tour AD IZ , like all of the premium Tour AD wood shafts, utilizes premium, aerospace quality
50t carbon-fiber materials in order to deliver the best feeling and performing shaft available to
golfers.

The new Tour AD IZ shaft has a firm stiffness starting at the handle, and medium center section and
a firm+ tip profile to promote a high launch angle and low ball spin rates. The new Tour AD IZ also
utilizes TORAYCA ® T1100G carbon-fiber pre-preg with NANOALLOY ® technology in the tip section
of the shaft for additional shaft stability, exceptional feel and precise ball control.

Reach out to your local Golf Club Fitting professional and ask about how to get your Driver or
Fairway metal wood “ Into the Zone” using the new Tour AD IZ model of premium Graphite Design
graphite golf shafts.

MSI_side_image

Features & Technology:

  • TORAYCA ® T1100G carbon-fiber pre-preg with NANOALLOY ® technology for increased stability in the mid to tip region and unsurpassed feel.
  • 50 ton ultra-premium, high modulus, aerospace quality carbon fiber materials.
  • Graphite Design proprietary Material Stiffness Integration (MSI) design philosophy and technology.

Bend Profile:

SHAFT TIP Section MID Section BUTT Section
IZ-4 SOFT MEDIUM MEDIUM
IZ-5,-6,-7,-8 FIRM+ MEDIUM FIRM
CompareShafts Trimming/Fitting Guide BuyNow

Performance:

  • IZ-4 is designed to promote High Launch angles with Low/Mid ball spin rates.
  • IZ-5, -6, -7, and -8 are designed to promote High Launch angles with Low ball spin rates.
  • MSRP $500

Fitting:

71-85 MPH 86-95 MPH 92-98 MPH 96-105 MPH 105+ MPH
R2 Flex
(Lite/Senior)
R1 Flex
(Regular)
SR Flex
(Stiff Regular)
S Flex
(Stiff)
X Flex
(X-Stiff)

Tip Trimming for Std Bore:

Driver 3 Wood 5 Wood 7 Wood 9 Wood
0″ 0.5″ 1.0″ 1.0″ 1.0″
  • Pro’s Choice encourages consulting a PGA Professional or qualified club builder to help you determine the correct shaft and length for your swing profile and to meet your goals.
  • Always leave a minimum of 0.5″ of the parallel tip section of the shaft above the hosel. For example with a hosel depth of 1.5″ and a parallel tip length of 4.0″, the tip trim length should not exceed 2.0″.
  • Improper installation may affect the intended performance of the shaft. Warranty is for material and workmanship of our products. Improper installation voids warranty of product.

Specifications:

Shaft Type Part Number Flex Length Wt. Tip OD Tip Para. Butt OD Torque Kick pt Launch Spin
TOUR AD IZ 4 R2 ADIZ4-R2 Lite/ Senior 46″ 46g .335″ 3.0″ .590″ 5.6 MID HIGH LOW/MID
TOUR AD IZ 4 R1 ADIZ4-R1 Regular 46″ 47g .335″ 3.0″ .590″ 5.6 MID HIGH LOW/MID
TOUR AD IZ 4 S ADIZ4-S Stiff 46″ 47g .335″ 3.0″ .592″ 5.6 MID HIGH LOW/MID
TOUR AD IZ 5 R2 ADIZ5-R2 Lite/ Senior 46″ 52g .335″ 3.0″ .594″ 4.5 MID HIGH LOW/MID
TOUR AD IZ 5 R1 ADIZ5-R1 Regular 46″ 54g .335″ 3.0″ .596″ 4.5 MID HIGH LOW
TOUR AD IZ 5 S ADIZ5-S Stiff 46″ 56g .335″ 3.0″ .598″ 4.4 MID HIGH LOW
TOUR AD IZ 5 X ADIZ5-X X-Stiff 46″ 58g .335″ 3.0″ .600″ 4.4 MID HIGH LOW
TOUR AD IZ 6 SR ADIZ6-SR Stiff Regular 46″ 62g .335″ 3.0″ .596″ 3.2 MID HIGH LOW
TOUR AD IZ 6 S ADIZ6-S Stiff 46″ 63g .335″ 3.0″ .598″ 3.2 MID HIGH LOW
TOUR AD IZ 6 X ADIZ6-X X-Stiff 46″ 65g .335″ 3.0″ .600″ 3.2 MID HIGH LOW
TOUR AD IZ 7 S ADIZ7-S Stiff 46″ 72g .335″ 3.0″ .598″ 3.1 MID HIGH LOW
TOUR AD IZ 7 X ADIZ7-X X-Stiff 46″ 74g .335″ 3.0″ .600″ 3.1 MID HIGH LOW
TOUR AD IZ 8 S ADIZ8-S Stiff 46″ 82g .335″ 3.0″ .604″ 2.9 MID HIGH LOW
TOUR AD IZ 8 X ADIZ8-X X-Stiff 46″ 83g .335″ 3.0″ .608″ 2.9 MID HIGH LOW
