Tour AD F-Series Shafts



Designed and manufactured at the Graphite Design Japan factory headquarters, the Tour AD F-Series Fairway shafts are available in 55g R2, R1 and S Flex, 65g SR (Stiff Regular), S and X flex, 75g S and X flex and 85g S and X flex.

The Tour AD F-Series Fairway shafts are designed with a softer tip and stiffer butt profile and feature a Low Kick Point for higher launch conditions into the air and mid-ball spin. Manufactured under the same tight tolerances and with premium, aerospace quality 40t carbon-fiber materials, the Tour AD F-Series of shafts fall directly in line with all of the other high quality Graphite Design shafts as a complementing Fairway wood shaft.

Should you be searching for a new Fairway shaft that is designed to provide maximum distance and extra forgiveness off the fairways, then a new Tour AD F-Series Fairway graphite shaft may be the answer to what you are looking for in a high performance golf shaft for your Fairway metal-woods. Revolutionary technology, design and the most advanced materials are trademarks in all Graphite Design shafts, resulting in the highest quality premium golf shafts on the market today. Validating the company’s “Tour AD” logo, all of Graphite Design’s Tour proven shafts are specifically designed to promote a gain in Accuracy and Distance.

MSI_side_image

Features & Technology:

  • 40t High modulus, premium aerospace quality carbon fiber materials.
  • Graphite Design proprietary Material Stiffness Integration (MSI) design philosophy and technology.

Bend Profile:

BUTT Section MID Section TIP Section
FIRM MEDIUM SOFT

Performance:

  • Designed to promote High launch angles with Mid ball spin rates.
  • MSRP $300

Fitting

Shaft Flex Fitting recommendations are based on the player’s Driver Swing Speed
71-85 MPH 86-95 MPH 92-98 MPH 96-105 MPH 105+ MPH
 R2 Flex
(Lite/Senior)
 R1 Flex
(Regular)
 SR Flex
(Stiff Regular)
S Flex
(Stiff)
 X Flex
(X-Stiff)

Tip Trimming for Standard Bore:

3 Wood 5 Wood 7 Wood 9 Wood
0.5″ 1″ 1″ 1″
  • Pro’s Choice encourages consulting a PGA Professional or qualified club builder to help you determine the correct shaft and length for your swing profile and to meet your goals.
  • Always leave a minimum of 0.5″ of the parallel tip section of the shaft above the hosel to maintain shaft durability and prevent shaft failure/breakage.  For example, if the head has a hosel bore depth of 1.5″ and the shaft has a parallel tip length of 3.0″, the tip trim length should not exceed 1.0″.
  • Improper installation may affect the intended performance of the shaft. Warranty is for material and workmanship of our products. Improper installation voids warranty of product.

Specifications:

Shaft Type Part Number Flex Length Wt. Tip OD Tip Para. Butt OD Torque Kick pt Launch Spin
Tour AD F-55 R2 ADFW5-R2 Lite/Senior 44″ 59g .335″ 3.0″ .598″ 5.0 LOW HIGH MID
Tour AD F-55 R1 ADFW5-R1 Regular 44″ 60g .335″ 3.0″ .598″ 5.0 LOW HIGH MID
Tour AD F-55 S ADFW5-S Stiff 44″ 60g .335″ 3.0″ .602″ 5.0 LOW HIGH MID
Tour AD F-65 SR ADFW6-SR Stiff Regular 44″ 68g .335″ 3.0″ .604″ 3.3 LOW HIGH MID
Tour AD F-65 S ADFW6-S Stiff 44″ 68g .335″ 3.0″ .604″ 3.3 LOW HIGH MID
Tour AD F-65 X ADFW6-X X-Stiff 44″ 70g .335″ 3.0″ .604″ 3.3 LOW HIGH MID
Tour AD F-75 S ADFW7-S Stiff 44″ 77g .335″ 3.0″ .598″ 3.2 LOW HIGH MID
Tour AD F-75 X ADFW7-X X-Stiff 44″ 79g .335″ 3.0″ .602″ 3.2 LOW HIGH MID
Tour AD F-85 S ADFW8-S Stiff 44″ 89g .335″ 3.0″ .602″ 2.8 LOW HIGH MID
Tour AD F-85 X ADFW8-X X-Stiff 44″ 91g .335″ 3.0″ .604″ 2.8 LOW HIGH MID
